Testing JSF applications

with Arquillian and Selenium

  • Brian Leathem and Lincoln Baxter, III
  • Senior Software Engineers, Red Hat
  • JavaOne 2012 - San Francisco
  • 2012-09-04

The plan

  • Brief Review of back-end testing
  • How to test the front-end with Selenium
  • Beyond Selenium with Arquillian Extensions
http://www.flickr.com/photos/jdhancock/5845280258/

Who are we?

  • Senior Software Engineers at Red Hat
  • RichFaces and Forge Project Leads
  • Represent Red Hat on the JSF 2.2 EG (JSR-344)
http://leslycorazon.wikispaces.com/file/detail/head-silhouette-with-question-mark.png/319199232

Who's behind all this?

  • Lukáš Fryč ( @lfryc )
  • Arquillian Graphene Lead, Arquillian Warp Lead
  • Juraj Huska ( @j_huska )
  • Arquillian Graphene, Arquillian Drone
  • Jan Papoušek ( @jan_papousek )
  • Arquillian Graphene, Arquillian Drone

Who are you?

Can I see a show of hands for those...
  • Who currently develop web applications with JSF?
  • Who are using Arquillian to test their application logic?
  • Who are using Selenium to test their application front-end?

Back-end testing

A well understood problem

Back-end testing | Unit tests

JUnit / TestNG

  • Easy to test self-contained logic
  • Mocks allow us to extend unit tests further

Back-end testing | "Real" tests

"Real tests"

  • Test code in-container
  • No "surprises" in production

Enter Arquillian

Don't mock me!

  • Bring the container to the test
  • Micro-deployments

Example | GreeterTest

Hello
World!

  • Basic Arquillian test
  • Demonstrate @Inject
  • Introduce Shrinkwrap

GreeterTest | The Bean

public class Greeter {

    private PhraseBuilder phraseBuilder;

    @Inject
    public Greeter(PhraseBuilder phraseBuilder) {
        this.phraseBuilder = phraseBuilder;
    }

    public void greet(PrintStream to, String name) {
        to.println(createGreeting(name));
    }

    public String createGreeting(String name) {
        return phraseBuilder.buildPhrase("hello", name);
    }
}

GreeterTest | Injection

public class PhraseBuilder {
    private Map<String, String> templates;

    public String buildPhrase(String id, Object... args) {
        return MessageFormat.format(templates.get(id), args);
    }

    @PostConstruct
    public void initialize() {
        templates = new HashMap<String, String>();
        templates.put("hello", "Hello, {0}!");
    }
}

GreeterTest | Test

@RunWith(Arquillian.class)
public class GreeterTest {
    @Deployment
    public static JavaArchive createDeployment() {
        JavaArchive jar = ShrinkWrap.create(JavaArchive.class)
            .addClasses(Greeter.class, PhraseBuilder.class)
            .addAsManifestResource(EmptyAsset.INSTANCE, "beans.xml");
        return jar;
    }

    @Inject
    Greeter greeter;

    @Test
    public void should_create_greeting() {
        Assert.assertEquals("Hello, Earthling!",
            greeter.createGreeting("Earthling"));
    }
}

The Magic

  • POM Dependencies
    • Arquillian
    • JUnit | TestNG
    • Deployment Container
  •
  • Arquillian.xml
    • Configuration of the test container

GreeterTest | POM

<profile>
    <id>arquillian-jbossas-managed</id>
    <dependencies>
        ...
        <dependency>
            <groupId>org.jboss.as</groupId>
            <artifactId>jboss-as-arquillian-container-managed</artifactId>
            <version>7.1.1.Final</version>
            <scope>test</scope>
        </dependency>

        <dependency>
            <groupId>org.jboss.arquillian.protocol</groupId>
            <artifactId>arquillian-protocol-servlet</artifactId>
            <scope>test</scope>
        </dependency>

    </dependencies>
</profile>

Demo Time

Front-end Testing

Ideal: Pyramid of test coverage

http://watirmelon.files.wordpress.com/2012/01/idealautomatedtestingpyramid.png

Reality: Ice-cream Cone of test coverage

http://watirmelon.files.wordpress.com/2012/01/softwaretestingicecreamconeantipattern.png

Howto increase automated test coverage?

  •
  • Unit tests of GUI code -- lots of mocks!
  •
  • Let's focus on real-tests

Real tests → real browsers

Selenium


Selenium automates browsers. That's it.

WebDriver API:

  • Unified API for all browsers
  • Headless tests via HtmlUnit

Selenium | API


WebDriver


Represents the web browser


  • Methods:
    • .get()
    • .findElement(By)

Selenium | API


WebElement


Represents an HTML element.


  • Methods:
    • .click()
    • .sendKeys()
    • .getText()
    • .findElement(By)

WebElement Lookup


Selenium/WebDriver programmatic API:

WebElement username
    = driver.findElement(By.id("username"))

Alternative @FindBy annotation:

@FindBy(id="username")
WebElement username;
...
PageFactory.initElements(driver, this);
  • By.ByClassName, By.ByCssSelector, By.ById, By.ByLinkText, By.ByName, By.ByPartialLinkText, By.ByTagName, By.ByXPath, ByChained, ByIdOrName

Selenium IDE - Easy!

  • Easy to write/record tests
  • Replay tests against all browsers

Example | Selenium

Selenium
IDE

Selenium Ex. | The Test

public class SeleniumTest {
    private WebDriver driver;
    private String baseUrl;
    private StringBuffer verificationErrors = new StringBuffer();

    @Before
    public void setUp() throws Exception {
      driver = new FirefoxDriver();
      baseUrl = "http://kitchensink-richfaces.rhcloud.com/";
      driver.manage().timeouts().implicitlyWait(30, TimeUnit.SECONDS);
    }

    @Test
    public void test() throws Exception {
      driver.get(baseUrl + "/");
      driver.findElement(By.id("reg:memberForm:name")).clear();
      driver.findElement(By.id("reg:memberForm:name")).sendKeys("Brian Leathem");
      driver.findElement(By.id("reg:memberForm:email")).clear();
      driver.findElement(By.id("reg:memberForm:email")).sendKeys("[email protected]");
      driver.findElement(By.id("reg:memberForm:phoneNumber")).clear();
      driver.findElement(By.id("reg:memberForm:phoneNumber")).sendKeys("234234234235");
      driver.findElement(By.id("reg:register")).click();
      Thread.sleep(2000);
      try {
        assertEquals("Brian Leathem", driver
          .findElement(By.id("reg:memberTable:0:member_name")).getText());
      } catch (Error e) {
        verificationErrors.append(e.toString());
      }
    }

    @After
    public void tearDown() throws Exception {
      driver.quit();
      String verificationErrorString = verificationErrors.toString();
      if (!"".equals(verificationErrorString)) {
        fail(verificationErrorString);
      }
    }
}

Demo Time

Selenium - Problems!

Not enough abstraction, Highly repetitive

→ Maintenance problem

http://www.flickr.com/photos/cellardoorfilms/7620375702/
  • Tests focus against state transitions
  • Test only DOM/CSS expressed directly in the test

Automating Client-side testing

  • Deploy the app, run the tests!
http://www.flickr.com/photos/pasukaru76/6893926948/

Container lifecycle

Ike has us covered!

  • Startup/shutdown the container
  • Create the testable archive
  • Deploy the application

Client lifecycle?

  • Start / Stop the Browser

Arquillian Extensions

Arquillian Drone
Brings the browser to the test
Arquillian Graphene
Selenium integration and extension
Arquillian Warp
Testing on both sides of the request

Arquillian Drone

Manages the browser life-cycle

Arquillian Drone

  • Integrates with:
    • Selenium/Webdriver
    • Arquillian Graphene
@Drone
WebDriver browser

<extension qualifier="webdriver">
    <property name="browserCapabilities">chrome</property>
</extension>

Separation of concerns

Devs focus: Author tests

http://www.flickr.com/photos/metrolibraryarchive/3267555668/
http://www.flickr.com/photos/metrolibraryarchive/3267249336/

QA focus: Automate tests

Example | Google Drone Test

  • Simple Drone test
  • Demonstrate @Drone

Google Drone Test | Test

@RunWith(Arquillian.class)
public class GoogleDroneTest {

    @Drone
    WebDriver browser;

    @Test
    public void testOpeningHomePage() {
        browser.get("http://www.google.com/");
        List<WebElement> elements = browser.findElements(
            By.xpath("//span[contains(text(), 'Google Search')]"));

        Assert.assertTrue("Page not loaded", elements.size() > 0);
    }
}

Demo Time

Arquillian Graphene

http://www.flickr.com/photos/core-materials/5057399792/

Selenium Arquillian-Style

  • Arquillian integration starts with Drone and the instantiation of the WebDriver instance.
  • Graphene then takes new instance of WebDriver's browser session and store is in its Thread Local Context.
  • Graphene also wraps the WebDriver instance in order to intercept calls.

Graphene 1.0

GrapheneSelenium class
type-safe Selenium class for Selenium 1.x
@Drone
GrapheneSelenium browser;

Graphene 2.0

  • More Injection
  • More Abstractions
  • More Extensions

Page Abstractions

Encapsulate DOM elements behind a custom API

Selenium | Page objects

  • A class that encapsulates the behaviour of a page

Selenium | LoginPage

public class LoginPage {
    private final WebDriver driver;

    public LoginPage(WebDriver driver) {
        this.driver = driver;
    }

    public HomePage loginAs(String username, String password) {
        driver.findElement(By.id("username")).sendKeys(username);
        driver.findElement(By.id("passwd")).sendKeys(password);
        driver.findElement(By.id("login")).submit();

        return new HomePage(driver);
    }
}

Selenium | Page Instantiation

Selenium PageFactory class instantiates Page Objects:

LoginPage loginPage =
    PageFactory.initElements(driver, LoginPage.class);

Graphene | Page Injection

Graphene test enrichment manages the PageFactory

@Page
LoginPage loginPage
@FindBy(id="username")
WebElement username;

Graphene | Page Fragments

  • Page Objects ++
  • Encapsulate the behaviour of a page fragment


@FindBy(css=".calendar")
CalendarFragment calendar;

Abstraction FTW!

Single place to update WebDriver code
when the underlying DOM changes

Waiting...

Simplest case:

Thread.sleep(2000);

Selenium provides the WebDriverWait class

WebElement myDynamicElement = (new WebDriverWait(driver, 10))
  .until(new ExpectedCondition<WebElement>(){
  @Override
  public WebElement apply(WebDriver d) {
    return d.findElement(By.id("myDynamicElement"));
  }});

More boiler plate!

Graphene wait helpers

Helper Description Timeout
waitGui() waits for a short time
eg. wait for client-side operations
1
waitAjax() waits for longer time
eg. wait for simple ajax request
2
waitModel() waits for a long time
eg. wait for database requests
5

Wait helper Usage

By id = By.id("button");
WebElement element = driver.findElement(id);
...
waitModel(element(id).isVisible));
...
waitModel(element(element).not().textContains("blahblah"));
...
waitModel(attribute(id, "value").valueContains("blahblah"));
...
waitModel(attribute(element, "value").not().valueEquals("blahblah"));

Request guards

http://www.flickr.com/photos/abennett96/2717629123/

Blocks the Selenium test execution until a network communication caused by a given action ends

guardHttp(button).click();
blocks on HTTP
guardXhr(button).click();
blocks on XHR (Ajax)

Request guard | Usage

@RunWih(Arquillian.class)
public class TestClass {

    @FindBy(id="http")
    private WebElement httpButton;

    @FindBy(id="xhr")
    private WebElement xhrButton;

    @Test
    public void testSimple() {
        guardHttp(httpButton).click();
        guardXhr(xhrButton).click();
    }
}

Javascript Interfaces

Execute JavaScript from your Java test

@JavaScript("javascriptObject")
@Dependency(sources = {"file.js"})
public interface Background {
    void voidMethod(String color);
    String someFunction();
}

Example | Javascript Interface

  • Manipulate the DOM
  • Bi-directional communication

Example | Javascript Interface

BackGround.java:

@JavaScript("myBackground")
@Dependency(sources = {"background.js"})
public interface Background {
    void setBackground(String color);
    String getBackground();
}

background.js:

myBackground = {
    setBackground : function (color) {
        document.body.style.background = color;
    },

    getBackground : function () {
        return document.body.style.background;
    }
}

Example | Javascript Interface

@RunWith(Arquillian.class)
public class JavaScriptTest {

    @Drone
    WebDriver browser;

    @Test
    public void testOpeningHomePage() throws  Exception {
        browser.get("http://www.google.com/");
        Background background = JSInterfaceFactory.create(Background.class);

        System.out.println(String.format(
            "Background color is: %s", background.getBackground()));

        background.setBackground("red");
        System.out.println(String.format(
            "Background color is: %s", background.getBackground()));
        Thread.sleep((2000));

        background.setBackground("");
        System.out.println(String.format(
            "Background color is: %s", background.getBackground()));
        Thread.sleep((2000));
    }
}

Demo Time

Page Extensions

Automatically include Javascript Interfaces in your tests


Simply:

  • Implement an interface
  • Register the extension


See the docs...

https://docs.jboss.org/author/display/ARQGRA2/Page+Extensions

Request Guards | Impl

@JavaScript(value = "Graphene.Page.RequestGuard")
@Dependency(sources = "Graphene.Page.RequestGuard.js",
            interfaces=XhrInterception.class)
public interface RequestGuard extends InstallableJavaScript {

    /**
     * @return the last request type
     */
    RequestType getRequestDone();

    /**
     * Clears the request type cache and returns the last
     * request type
     * @return the last request type
     */
    RequestType clearRequestDone();

}

Interceptors with Graphene

Work is in progress to port the Graphene 1 interceptor API to Graphene 2

  • Code executed around each WebDriver invocation
  • Cross-cutting concerns


https://issues.jboss.org/browse/ARQGRA-79
  • execute code before/after the selenium command will be performed
  • catch exceptions thrown when performing selenium command

Example | LoginScreen

  • Graphene Test
  • Demonstrate Page Fragments

LoginScreen | Deployment

public class Deployments {
    public static final String WEBAPP_SRC = "src/main/webapp";

    public static WebArchive getLoginScreenDeployment() {
        return ShrinkWrap.create(WebArchive.class, "login.war")
                .addClasses(Credentials.class, User.class, LoginController.class)
                .addAsWebResource(new File(WEBAPP_SRC, "resources/bootstrap/css/bootstrap.css"),
                                  "resources/bootstrap/css/bootstrap.css")
                .addAsWebResource(new File(WEBAPP_SRC, "login.xhtml"))
                .addAsWebResource(new File(WEBAPP_SRC, "home.xhtml"))
                .addAsWebInfResource(EmptyAsset.INSTANCE, "beans.xml")
                .addAsWebInfResource(
                        new StringAsset("<faces-config version=\"2.0\"/>"),
                        "faces-config.xml");
    }

}

LoginScreen | GrapheneTest

@RunWith(Arquillian.class)
public class LoginScreenGrapheneTest {

    @Deployment(testable = false)
    public static WebArchive createDeployment() {
        return Deployments.getLoginScreenDeployment();
    }

    @Drone
    WebDriver browser;

    @ArquillianResource
    URL contextPath;

    @FindBy(id="loginForm:username")
    private WebElement usernameInput;

    @FindBy(id="loginForm:password")
    private WebElement passwordInput;

    @FindBy(id="loginForm:login")
    private WebElement loginButton;

    @Test
    @RunAsClient
    public void should_login_successfully() throws Exception {
        String page = contextPath + "login.jsf";
        browser.get(page);

        usernameInput.sendKeys("demo");
        passwordInput.sendKeys("demo");
        loginButton.click();

        Assert.assertTrue("User should be logged in!",
                browser.findElements(By.xpath("//li[contains(text(), 'Welcome')]")).size() > 0);
    }

}

LoginScreen | LoginFragment

public class LoginFragment {

    @FindBy(id="loginForm:username")
    private WebElement usernameInput;

    @FindBy(id="loginForm:password")
    private WebElement passwordInput;

    @FindBy(id="loginForm:login")
    private WebElement loginButton;

    public void setUsername(Object username) {
        usernameInput.sendKeys(username.toString());
    }

    public void setPassword(Object password) {
        passwordInput.sendKeys(password.toString());
    }

    public void click() {
        loginButton.click();
    }
}

LoginScreen | FragmentTest

@RunWith(Arquillian.class)
public class LoginScreenFragmentTest {

    @Deployment(testable = false)
    public static WebArchive createDeployment() {
        return Deployments.getLoginScreenDeployment();
    }

    @Drone
    WebDriver browser;

    @ArquillianResource
    URL contextPath;

    @FindBy(id="loginForm")
    LoginFragment loginForm;

    @Test
    @RunAsClient
    public void should_login_successfully() {
        String page = contextPath + "login.jsf";
        browser.get(page);

        loginForm.setUsername("demo");
        loginForm.setPassword("demo");
        loginForm.click();

        Assert.assertTrue("User should be logged in!",
                browser.findElements(By.xpath("//li[contains(text(), 'Welcome')]")).size() > 0);
    }

}

Arquillian Warp

  • Testing on both sides of the request
  • En-rich the client request with a test to run on the server
  • En-rich the server response with results of the test

JSFUnit | the old way

  • HtmlUnit - no real browsers
  • Assert state only at the end of the JSF lifecycle
  • JSF Only (No CDI, EJB etc.)

Warp | the new way

  • Advantages:
    • Selenium / any HTTP client
    • Test the entire JSF lifecycle
    • Test any injectable resource
      • CDI
      • EJB
      • Any framework!
  • Not just JSF

Warp | Example

@WarpTest
@RunWith(Arquillian.class)
public class LoginScreenWarpTest {

    @Deployment
    public static WebArchive createDeployment() {
        WebArchive webArchive = Deployments.getLoginScreenDeployment();
        webArchive.delete("WEB-INF/beans.xml");
        webArchive.addAsWebInfResource(new File("src/test/resources/beans.xml"));
        return webArchive;
    }

    @Drone
    WebDriver browser;

    @ArquillianResource
    URL contextPath;

    @FindBy(id="loginForm")
    LoginFragment loginForm;

    @Test
    @RunAsClient
    public void should_login_successfully() {
        String page = contextPath + "login.jsf";
        browser.get(page);

        Warp.filter(new JsfRequestFilter()).execute(new ClientAction() {
            @Override
            public void action() {
                loginForm.setUsername("demo");
                loginForm.setPassword("demo");
                loginForm.click();
            }
        }).verify(new CheckUsername());

        Assert.assertTrue("User should be logged in!",
                browser.findElements(By.xpath("//li[contains(text(), 'Welcome')]"))
                    .size() > 0);
    }

    public static class CheckUsername extends ServerAssertion {
        @Inject
        Credentials credentials;

        @BeforePhase(Phase.UPDATE_MODEL_VALUES)
        public void beforeUpdateModelValues() {
            Assert.assertNull(credentials.getUsername());
        }

        @AfterPhase(Phase.UPDATE_MODEL_VALUES)
        public void afterUpdateModelValues() {
            Assert.assertEquals("demo", credentials.getUsername());
        }

    }

}

Demo Time

Reducing test development turnaround

Best practices

  • Use a Remote Container
  • Re-usable Browser Session
  • Use Shrinkwrap micro-deployments
    • Share deployments across tests
  • Arquillian jRebel extension

The end?

The beginning - of JSF testing adventure with Arquillian and Selenium!

Credits

Additional Resources

Arquillian @ JavaOne

  • TUT5039 – Cover Your Web and Mobile Applications with Integration Tests from Scratch
  • CON7469 – Apache TomEE, a Java EE 6 Web Profile on Tomcat
  • CON2818 – A Bird’s-Eye View of the CDI Ecosystem
  • CON5312 – Continuous Enterprise Development: Case Studies in Java EE Integration Testing
  • CON6918 – The Arquillian Universe: A Tour Around the Astrophysics Lab
  • BOF7997 – A New Approach to Testing Your Java EE Applications Deployed on a PaaS
  • CON7622 – Testing JSF Applications with Arquillian and Selenium
  • CON5458 – Today’s Rapid Java EE Development: Live Coding from Scratch to Deployment

Stay in the loop
